EEG sensors and electrodes for neurophysiology and sleep labs
EEG/EMG lines14 + electrode range
ElectrodesGold cup · ear clip
Connectors1.5 mm DIN safety
AlsoPre-wired sets
EEG work rewards boring consistency: the same electrode metal, the same lead length, the same connector, study after study. This range covers reusable gold cup electrodes (1.5 m leads, 1.5 mm DIN safety touch-proof connectors), ear-clip electrodes, disposable cup and pre-wired electrode options, and the snap leadwire sets that carry EMG and evoked-potential work — the accessories neurophysiology and sleep departments reorder on a cycle.
The EEG line shares its shelf logic with the ECG electrode range — same DIN safety connector convention, same catalogue — so a sleep lab can source its PSG electrodes, its monitoring electrodes and its leadwires against one specification instead of three.
Cup electrodes and leadwires
Gold cup electrodes remain the reusable standard for routine EEG: a 10 mm-class cup, moulded lead and touch-proof DIN termination, cleaned and re-gelled between patients. Ear-clip electrodes serve the A1/A2 reference positions. For high-turnover or infection-controlled work, disposable cup electrodes and pre-wired sets trade a small per-study premium for zero reprocessing; both formats are in the catalogue with the same 1.5 mm DIN safety plug.
- Reusable gold cup electrodes, colour-coded lead sets
- Ear-clip reference electrodes
- Disposable EEG cup electrodes and pre-wired EMG/EEG leadwire sets
Specifying for your amplifier
EEG accessories are amplifier-specific at exactly one point: the connector. The 1.5 mm DIN 42802 touch-proof plug is the common standard across modern amplifiers; older or specialist systems differ. State the amplifier brand and model (or photograph the input panel) and the lead length you run — 1.0 m and 1.5 m are the common lengths — and the set is matched before quotation.
Representative products from the current catalogue
| Product (official store listing) | Key specifications |
|---|---|
| 2mm Pin Biomedical Connector for ECG EGM EEG EMG Signal Acquisition, 5.6mm Sleeve, Custom Cable Assembly | Specification: Details；Pin diameter: 2mm standard medical pin；Outer sleeve diameter: 5.6mm；Contact plating: Gold plated (low contact resistance, anti-oxidation)；Sheath material: Medical grade TPU, biocompatible, disinfectant-resistant；Produ |
| Compatible Draeger Adapter Cable BISx Anesthesia EEG -2607560 | Draeger: 2607560；Category: Anesthesia Adapter Cables；Instrument Connector: 7 pin Lemo Connector；Patient end connector: 12 pin Connector；Total Cable Length: 0.45m；Cable Diameter: 5.0 mm；Packaging Unit: 1；Weight: 0.25lb；Anesthesia EEG Tech.: |
| Covidien Compatible Anesthesia EEG Adapter Cables -186-0107 | Medtronic -Covidien: 186-0107；Mindray: 0010-10-42672；GE Healthcare: CARESCAPE series: B450,B650,B850 etc. B20、B40 ;B105, B125, B155，B105P, B125P,B105M, B125M,B155M etc. Datex Ohmeda Monitors S/5.Dash 3000、4000、5000；Comen: K series.C series |
| Covidien Compatible Anesthesia EEG Adapter Cables -186-1018 | Medtronic -Covidien: 186-1018；Mindray: 0010-10-42672；GE Healthcare: CARESCAPE series: B450,B650,B850 etc. B20、B40 ;B105, B125, B155，B105P, B125P,B105M, B125M,B155M etc. Datex Ohmeda Monitors S/5.Dash 3000、4000、5000；Comen: K series.C series |
| Covidien Compatible Disposable Anesthesia EEG Sensors - 186-0106 (10pcs/box) | Medtronic -Covidien: 186-0106；Mindray: 0010-10-42672；GE Healthcare: CARESCAPE series: B450,B650,B850 etc. B20、B40 ;B105, B125, B155，B105P, B125P,B105M, B125M,B155M etc. Datex Ohmeda Monitors S/5.Dash 3000、4000、5000；Comen: K series.C series |
| Covidien Compatible Disposable Anesthesia EEG Sensors - 186-0200 (10pcs/box) | Medtronic -Covidien: 186-0200；Mindray: 0010-10-42672；GE Healthcare: CARESCAPE series: B450,B650,B850 etc. B20、B40 ;B105, B125, B155，B105P, B125P,B105M, B125M,B155M etc. Datex Ohmeda Monitors S/5.Dash 3000、4000、5000；Comen: K series.C series |
Questions & answers
Are the cup electrodes reusable?
The gold cup electrodes are reusable (clean and re-gel per your lab protocol). Disposable cup and pre-wired options are also stocked for single-patient use.
Which connector do the EEG leads use?
1.5 mm DIN safety (touch-proof) plugs are standard across this range. Confirm your amplifier's input type when ordering.
Can I source PSG accessories together?
Yes — EEG electrodes, monitoring electrodes and leadwires sit in one catalogue and can ship as one order.
